ManufacturerRealMan Intelligent Technology (Beijing) Co., Ltd.Robot model · No. 4

Single-Arm Lift

Mobile Manipulation Robots (MMRRs) · Logistics & Warehousing

CommercialChina
Key fact6 DoF, based on RM65 family specification · RM65-B-V
Image coming soon

Single-Arm Lift robot by RealMan Intelligent Technology (Beijing) Co., Ltd.

Model details

Model specifications

Arm DoF6 DoF, based on RM65 family specification
Arm ModelRM65-B-V
Arm Reach610–627 mm depending RM65 configuration; exact B-V reach not separately disclosed
Arm Repeatability±0.05 mm for RM65 family
AvailabilityCommercially Available
Base Diameter505 mm
Camera / 3D Visionnot publicly disclosed as standard on current exact configuration
Charging Supply100–240 V AC, 50 Hz
Endurance3 hours
Full-Body ControlYes
LiDARnot publicly disclosed on current exact Single-Arm Lift page
Lift Stroke≈900 mm
ManipulationPrecise single-arm
ManufacturerRealMan Robotics
Maximum Travel Speed1 m/s
Mobile Positioning Accuracy<±5 cm
ModelSingle-Arm Lift
NationalityChina
NavigationAutonomous SLAM
Operating Temperature5–40°C
Overall Height1605 mm
Path PlanningYes
Related Legacy / Reseller NameRMC-LA / Compound Lifting Robot
Robot TypeSingle-arm lifting mobile manipulator
Single-Arm Payload5 kg
Total Weight≈100 kg
Turning Radius252.5 mm
Working VoltageDC 24 V

About the Single-Arm Lift

The RealMan Single-Arm Lift is a compact autonomous mobile manipulator combining a 6-DoF RM65-B-V arm, 5 kg arm payload, ~900 mm vertical lift, 505 mm circular mobile base, 1 m/s travel speed, <±5 cm autonomous positioning accuracy, 252.5 mm turning radius, and approximately 3 hours of runtime. It is intended for retail, logistics, industrial, commercial, research, and flexible multi-height manipulation applications.

Typical applications: Logistics & Warehousing, Manufacturing & Industrial Operations.
